SiSiB® LR6000
SiSiB® LR6000

Optical Liquid Silicone Rubber

It is a two parts and platinum curable liquid silicone rubber for injection molding or infusion molding for manufacturing various structure parts.


SiSiB® LR6000

Technical Data


Product

LR6030

LR6040

LR6050

Appearance

Transparent

Transparent

Transparent

Ratio A:B

1:1

1:1

1:1

Viscosity (Pa.s)

30-50

30-50

30-50

Light Transmittance (%)

Min. 94

Min. 94

Min. 94

Rebound (%)

Min. 70

Min. 60

Min. 45

Hardness (Shore A)

28-32

38-42

48-52

Tensile Strength (MPa)

Min. 3.5

Min. 4.0

Min. 5.0

Tear Strength (KN/m)

Min. 7

Min. 9

Min. 13

Elongation at Break (%)

Min. 300

Min. 300

Min. 300

Compression Set (%)

Max. 1.5

Max. 1.5

Max. 1.5

Refractive Index (25°C)

1.41

1.41

1.41


Product

LR6060

LR6070

LR6080

Appearance

Transparent

Transparent

Transparent

Ratio A:B

1:1

1:1

1:1

Viscosity (Pa.s)

30-50

30-50

30-50

Light Transmittance (%)

Min. 93

Min. 93

Min. 93

Rebound (%)

Min. 40

Min. 35

Min. 30

Hardness (Shore A) (°A)

58-62

68-72

78-82

Tensile Strength (MPa)

Min. 5.2

Min. 5.5

Min. 6.0

Tear Strength (KN/m)

Min. 15

Min. 15.5

Min. 16

Elongation at Break (%)

Min. 280

Min. 200

Min. 200

Compression Set (%)

Max. 1.5

Max. 1.5

Max. 1.5

Refractive Index (25°C)

1.41

1.41

1.41


Application



Packing and Storage



  • In the unopened original container it has a shelf life of one year in a dry and cool place.


Documents

DownloadSiSiB® LR6000 Technical Data Sheet
DownloadSiSiB® LR6000 Safety Data Sheet
