SiSiB® HR0600

General Heat Cured Silicone Rubber for Extrusion

SiSiB® HR06xx HR07xx HR08xx is heat cured silicone rubber for extrusion.

SiSiB® HR0600

Technical Data

Product	HR0650	HR0660	HR0670
Appearance	Transparent	Transparent	Transparent
Hardness (Shore A)	55+/-3	60+/-3	70+/-3
Williams Plasticity	230+/-20	290+/-30	365+/-55
Tensile Strength (MPa)	Min.7.0	Min.7.0	Min.6.0
Elongation (%)	Min. 300	Min. 300	Min. 200
Tensile Set (%)	Max. 8.0	Max. 10.0	Max. 10.0
Tear Strength (KN/m)	Min. 16.0	Min. 16.0	Min. 16.0
Curing Agent	C-8	C-8	C-8
Curing Agent Content	2.0%	2.0%	2.0%
Curing Condition	170°C×5min	170°C×5min	170°C×5min

Product	HR0760	HR0770	HR0870
Appearance	Transparent	Transparent	White
Hardness (Shore A)	60+/-2	69+/-3	73+/-3
Williams Plasticity	290+/-30	330+/-40	370+/-40
Tensile Strength (MPa)	Min.7.0	Min.6.0	Min.4.0
Elongation (%)	Min. 220	Min. 220	Min. 200
Tensile Set (%)	Max. 10.0	Max. 12.0	Max. 10.0
Tear Strength (KN/m)	Min. 16.0	Min. 15.0	Min. 14.0
Curing Agent	C-8	C-8	C-8E
Curing Agent Content	2.0%	2.0%	2.0%
Curing Condition	170°C×5min	170°C×5min	170°C×5min

Application

This high heat resistant silicone mold rubber is used for wire/cable, tubes, seals, parts.

Packing and Storage

SiSiB® HR06xx HR07xx HR0870 htv solid silicone rubber cord is supplied in 20Kg box, with plastic bag inside.

In the unopened original container it has a shelf life of one year in a dry and cool place.

Documents

Download

SiSiB® HR0600 Technical Data Sheet
