SiSiB® HR6000
SiSiB® HR6000

Flame Retardant Heat Cured Silicone Rubber

SiSiB® HR60xx is flame retardant heat cured elastomer with flammability UL94 V-0, suitable for cables, wires, parts.


SiSiB® HR6000

Technical Data


Product

HR6030

HR6040

HR6050

HR6060

Appearance

White

White

White

White

Hardness (Shore A)

30+/-3

40+/-3

50+/-3

60+/-3

Williams Plasticity

160+/-20

180+/-30

200+/-40

205+/-35

Tensile Strength (MPa)

Min.2.0

Min.3.0

Min.3.0

Min.4.5

Elongation (%)

Min. 500

Min. 400

Min. 350

Min. 220

Tensile Set (%)

Max. 12.0

Max. 12.0

Max. 10.0

Max. 12.0

Tear Strength (KN/m)

Min. 6.0

Min. 10.0

Min. 10.0

Min. 14.0

Curing Agent

C-8E

C-8E

C-8E

C-8E

Curing Agent Content

2.0%

2.0%

2.0%

2.0%

Curing Condition

170°C×5min

170°C×5min

170°C×5min

170°C×5min


Product

HR6070

HR6080

HR6090

Appearance

White

White

White

Hardness (Shore A)

70+/-3

80+/-3

87+/-3

Williams Plasticity

285+/-35

330+/-40

340+/-40

Tensile Strength (MPa)

Min.4.0

Min.3.5

Min.3.0

Elongation (%)

Min. 150

Min. 100

Min. 60

Tensile Set (%)

Max. 8.0

Max. 8.0

Max. 8.0

Tear Strength (KN/m)

Min. 10.0

Min. 12.0

Min. 12.0

Curing Agent

C-8E

C-8E

C-8E

Curing Agent Content

2.0%

2.0%

2.0%

Curing Condition

170°C×5min

170°C×5min

170°C×5min


Application


     This solid silicone cord is used for:


  • Wires and cables


  • Parts


Packing and Storage



  • In the unopened original container it has a shelf life of one year in a dry and cool place.


Documents

DownloadSiSiB® HR6000 Technical Data Sheet
DownloadSiSiB® HR6000 Safety Data Sheet
