Name: SiSiB® LR2335
Brand: Nanjing SiSiB Silicones Co., Ltd.
Price: 100 USD

Technical Data

Product	LR2335
Color	Black
Hardness (Shore A)	36 ~ 42
Tensile Strength (MPa)	Min. 6.5
Elongation (%)	Min. 640
Tear Strength (kN/m)	Min. 28
Compression Set at 120°C 300% tensile after 24 Hours (%)	Max. 12
Volume Resistivity (Ω.cm)	Max. 100

Curing condition: 10 minutes at 140°C and post cure 4 hours at 200°C.

Application

Liquid silicone rubber for mold making, semi conductive stress cone, shielding of intermediate joint for 35 kV and below.

In the unopened original container it has a shelf life of one year in a dry and cool place.

SiSiB® LR2335 Technical Data Sheet
