SiSiB® HR6200

Heat Resistant Heat Cured Silicone Rubber

SiSiB® HR62x1 is heat resistant products, can be used below 280°C.

SiSiB® HR62x3 is heat resistant products, can be used below 315°C.

SiSiB® HR6200

Technical Data

Product	HR6251	HR6261	HR6271
Appearance	Red or Translucent
Hardness (Shore A)	50+/-3	60+/-3	70+/-3
Williams Plasticity	215+/-25	260+/-30	285+/-35
Tensile Strength (MPa)	Min. 8.0	Min. 8.0	Min. 7.5
Elongation (%)	Min. 500	Min. 400	Min. 300
Tensile Set (%)	Max. 8.0	Max. 8.0	Max.8.0
Tear Strength (KN/m)	Min. 22.0	Min. 22.0	Min. 22.0
Curing Agent	C-15	C-15	C-15
Curing Agent Content	2.0%	2.0%	2.0%
Curing Condition	170°C×10min

Product	HR6253	HR6263	HR6273	HR6283
Appearance	Red or Translucent
Hardness (Shore A)	50+/-2	60+/-2	70+/-2	80+/-2
Williams Plasticity	185+/-25	260+/-30	310+/-30	330+/-40
Tensile Strength (MPa)	Min. 7.0	Min. 8.0	Min. 8.0	Min. 7.0
Elongation (%)	Min. 300	Min. 250	Min. 180	Min. 100
Tensile Set (%)	Max.10.0	Max. 10.0	Max. 10.0	Max.10.0
Tear Strength (KN/m)	Min. 16.0	Min. 16.0	Min. 16.0	Min. 15.0
Curing Agent	C-15	C-15	C-15	C-15
Curing Agent Content	2.0%	2.0%	2.0%	2.0%
Curing Condition	170°C×10min

Application

This solid silicone sheet is used for:

Auto accessories

Wires/Cables/Tubes

Parts

Seals

Packing and Storage

SiSiB® HR6200 htv silicone rubber product is supplied in 20Kg box, with plastic bag inside.

In the unopened original container it has a shelf life of one year in a dry and cool place.

Documents

Download

SiSiB® HR6200 Technical Data Sheet
