SiSiB® HR2300

Advanced Heat Cured Silicone Rubber for Extrusion

SiSiB® HR23xx is heat cured silicone rubber for extrusion.

SiSiB® HR2300

Technical Data

Product	HR2340	HR2350	HR2360	HR2370
Appearance	Transparent	Transparent	Transparent	Transparent
Hardness (Shore A)	40+/-2	50+/-2	60+/-3	70+/-3
Williams Plasticity	180+/-20	190+/-20	250+/-20	255+/-25
Tensile Strength (MPa)	Min.7.5	Min.8.0	Min.8.0	Min.7.5
Elongation (%)	Min. 600	Min. 500	Min. 400	Min. 300
Tensile Set (%)	Max. 8.0	Max. 8.0	Max. 8.0	Max. 8.0
Tear Strength (KN/m)	Min. 13.0	Min. 15.0	Min. 26.0	Min. 26.0
Curing Agent	C-15	C-15	C-15	C-15
Curing Agent Content	2.0%	2.0%	2.0%	2.0%
Curing Condition	170°C×10min	170°C×10min	170°C×10min	170°C×10min

Application

This solid silicone cord is used for:

Wire/Cable

Tubes

Parts

Packing and Storage

SiSiB® HR2300 htv heat resistant rubber tubing is supplied in 20Kg box, with plastic bag inside.

In the unopened original container it has a shelf life of one year in a dry and cool place.

Documents

Download

SiSiB® HR2300 Technical Data Sheet
