SiSiB® HR2000
SiSiB® HR2000

Advanced High Strength Heat Cured Silicone Rubber

SiSiB® HR20xx is high strength type heat cured elastomer for molding or extrusion.


SiSiB® HR2000

Technical Data


Product

HR2030

HR2040

HR2050

Appearance

Transparent

Transparent

Transparent

Hardness (Shore A)

30+/-2

40+/-2

50+/-2

Williams Plasticity

160+/-20

205+/-25

215+/-25

Tensile Strength (MPa)

Min.7.0

Min.8.0

Min.8.0

Elongation (%)

Min. 750

Min. 550

Min. 500

Tensile Set (%)

Max. 8.0

Max. 8.0

Max. 8.0

Tear Strength (KN/m)

Min. 14.0

Min. 18.0

Min. 26.0

Curing Agent

C-15

C-15

C-15

Curing Agent Content

2.0%

2.0%

2.0%

Curing Condition

170°C×10min

170°C×10min

170°C×10min


Product

HR2060

HR2070

HR2075

HR2080

Appearance

Transparent

Transparent

Transparent

Transparent

Hardness (Shore A)

60+/-2

70+/-2

75+/-2

80+/-3

Williams Plasticity

260+/-30

285+/-35

300+/-30

330+/-40

Tensile Strength (MPa)

Min.8.0

Min.7.5

Min.7.5

Min.7.5

Elongation (%)

Min. 400

Min. 300

Min. 300

Min. 200

Tensile Set (%)

Max. 8.0

Max. 8.0

Max. 12.0

Max. 8.0

Tear Strength (KN/m)

Min. 26.0

Min. 26.0

Min. 26.0

Min. 24.0

Curing Agent

C-15

C-15

C-15

C-15

Curing Agent Content

2.0%

2.0%

2.0%

2.0%

Curing Condition

170°C×10min

170°C×10min

170°C×10min

170°C×10min


Application


     This solid silicone rubber cord is used for:


  • Kitchenware


  • Skin for MP3/MP4/Mobile Phone


  • Wire/Cable


  • Tubes


  • Sealing, parts


Packing and Storage



  • In the unopened original container it has a shelf life of one year in a dry and cool place.


Documents

DownloadSiSiB® HR2000 Technical Data Sheet
DownloadSiSiB® HR2000 Safety Data Sheet
