SiSiB® HR0100
SiSiB® HR0100

General Purpose Heat Cured Silicone Rubber for Molding

SiSiB® HR0100 is general purpose heat cured elastomer for molding.


SiSiB® HR0100

Technical Data


Product

HR0130

HR0140

HR0150

Appearance

Translucent

Translucent

Translucent

Hardness (Shore A)

30+/-2

40+/-2

50+/-2

Williams Plasticity

130+/-20

160+/-20

215+/-24

Tensile Strength (MPa)

Min. 4.0

Min. 6.5

Min. 7.0

Elongation (%)

Min. 500

Min. 400

Min. 300

Tensile Set (%)

Max.10.0

Max.10.0

Max.10.0

Tear Strength (KN/m)

Min. 12.0

Min. 12.0

Min. 15.0

Linear Shrinkage (%)

3.3-3.8

3.2-3.7

3.1-3.6

Curing Agent

C-8

C-8

C-8

Curing Agent Content

2.0%

2.0%

2.0%

Curing Condition

170°C x 5min

170°C x 5min

170°C x 5min


Product

HR0160

HR0170

HR0180

Appearance

Translucent

Translucent

Translucent

Hardness (Shore A)

60+/-2

70+/-2

81+/-3

Williams Plasticity

240+/-30

330+/-40

340+/-40

Tensile Strength (MPa)

Min. 6.5

Min. 6.0

Min. 6.0

Elongation (%)

Min. 220

Min. 150

Min. 120

Tensile Set (%)

Max. 8.0

Max. 8.0

Max. 6.0

Tear Strength (KN/m)

Min. 14.0

Min. 14.0

Min. 16.0

Linear Shrinkage (%)

3.0-3.5

2.9-3.4

2.9-3.4

Curing Agent

C-8

C-8

C-8

Curing Agent Content

2.0%

2.0%

2.0%

Curing Condition

170°C x 5min

170°C x 5min

170°C x 5min


Application



Packing and Storage


  • SiSiB® HR0100 solid silicone rubber, high temperature vulcanized (htv on) silicone rubber, is supplied in 20Kg box, with plastic bag inside.


  • In the unopened original container it has a shelf life of one year in a dry and cool place.


Documents

DownloadSiSiB® HR0100 Technical Data Sheet
